| 2D Drawings | 2D Files |
|---|
| Accessories | Installation Socket Torque Tool 30215 |
|---|
| Coil Resistance | 122 |
|---|
| Connection | Spade Terminal, 0.110" |
|---|
| Connector | ET-C48 or ET-C120 or 3831-1-PKG |
|---|
| Current | 0.05A |
|---|
| Cycle Life | >1,000,000,000 (ideal applications) |
|---|
| Data Sheet | Data Sheet |
|---|
| Filtration | 40 micron (recommended) |
|---|
| Function | 2-Way Normally-Closed |
|---|
| Leak Rate | 0.1 sccm |
|---|
| Material, Seals | FKM |
|---|
| Material, Spring | ENP Nickel Alloy |
|---|
| Material, Wetted | ENP Brass, ENP Nickel Alloy, 430 Stainless Steel |
|---|
| Max PSI | 105 psig |
|---|
| Max. Flow | 17 l/min @ 100 psig |
|---|
| Medium | Clean, Dry Air & Compatible Gases |
|---|
| Mount | In-Line |
|---|
| Mounting | #6-32 Thread |
|---|
| Operating Pressure | 105 psig (17 l/min @ 100 psig) |
|---|
| Operating Temperature Range | 32 to 150°F (0 to 65°C) |
|---|
| Operating Voltage Range | 90 to 110% |
|---|
| Poppet Travel | 0.007" |
|---|
| Port Size | #10-32 Female In-Line |
|---|
| Product Line Brochure | Spider Valves |
|---|
| Response Time | 5 to 10 milliseconds (nominal) |
|---|
| Unit | Imperial |
|---|
| Voltage | 12 VDC |
|---|
| Wattage | 1.2 Watts (nominal) |
|---|
| Weight (lbs.) | 0.1700 |
|---|
