| Air Flow | 4.5 scfm @ 50 psig; 7.0 scfm @ 100 psig |
|---|---|
| Force | 48 oz. nominal |
| Input PSI | 150 psig max. |
| Mount | Dual #20 holes or 15/32-32 thd. |
| Nut Supplied | Yes |
| Ports | #10-32 Thread |
| Stem Travel | 1/8" |
| Temperature Range | 32 to 230°F |
| Weight (lbs.) | 0.1000 |
Notes
4.5 scfm @ 50 psig; 7.0 scfm @ 100 psig
