| Accessories | Installation Socket Torque Tool 30215 |
|---|
| Coil Resistance | 864 |
|---|
| Connection | Wire Leads Top (Axial), 18" |
|---|
| Current | 0.028A |
|---|
| Data Sheet | Data Sheet |
|---|
| Filtration | 40 micron (recommended) |
|---|
| Function | 2-Way Normally-Closed |
|---|
| Leak Rate | 0.1 sccm |
|---|
| Life Cycle | >1,000,000,000 (ideal applications) |
|---|
| Manifolds | Single & Multi-Station, Specialized |
|---|
| Material, Body | Nickel-Plated Brass, ENP Carbon Steel, Nickel Iron Alloy, 300 Stainless Steel |
|---|
| Material, Seals | Nitrile |
|---|
| Material, Spring | Nickel Alloy |
|---|
| Material, Wetted | ENP Brass, Nickel Alloy, Stainless Steel & ENP Steel |
|---|
| Max PSI | 7.2 bar |
|---|
| Max. Flow | 17 l/min @ 7 bar |
|---|
| Medium | Clean, Dry Air & Compatible Gases |
|---|
| Mount | Manifold |
|---|
| Operating Pressure | 105 psig (17 l/min @ 100 psig) |
|---|
| Operating Temperature Range | 32 to 180°F (0 to 82°C) |
|---|
| Operating Voltage Range | 90 to 150% |
|---|
| Product Line Brochure | Spider Valves |
|---|
| Response Time | 5 to 10 milliseconds (nominal) |
|---|
| Unit | Metric |
|---|
| Voltage | 24 VDC |
|---|
| Wattage | 0.67 Watts (nominal) |
|---|
| Weight (lbs.) | 0.1700 |
|---|
| Wire Size | 26 Gauge |
|---|
