Mounting Accessories

Spacers with and without L and T Brackets, for Clippard Maximatic FRLs
Spacers

Used to convert individual Filters, Regulators and Lubricators into combination units without mounting brackets. Seals included.

Dimensions - Spacers with and without L and T Brackets, for Clippard Maximatic FRLs
FRL Series Spacer Only L Bracket
with Spacer
T Bracket
with Spacer
L
FRL-1 MMH-Y10 MMH-Y10L MMH-Y10T 0.32"
FRL-2 MMH-Y20 MMH-Y20L MMH-Y20T 0.41"
FRL-3 MMH-Y30 MMH-Y30L MMH-Y30T 0.44"
FRL-4W, FRL-4Z MMH-Y40 MMH-Y40L MMH-Y40T 0.55"
FRL-4A MMH-Y50 MMH-Y50L MMH-Y50T 0.57"
FRL-5 MMH-Y60 MMH-Y60L MMH-Y60T 0.61"




Spacer with Auxiliary Port, for Clippard Maximatic FRLs
Spacers with Auxiliary Ports

Used to provide a parallel port between components.

Dimensions - Spacer with Auxiliary Port, for Clippard Maximatic FRLs
FRL Series Port Size Spacer Only L Bracket
with Spacer
T Bracket
with Spacer
L H W
FRL-2 1/8"
1/4"
MMH-Y21-N01
MMH-Y21-N02
MMH-Y21L-N01
MMH-Y21L-N02
MMH-Y21T-N01
MMH-Y21T-N02
0.41" 0.69" 0.76"
FRL-3 1/8"
1/4"
MMH-Y31-N01
MMH-Y31-N02
MMH-Y31L-N01
MMH-Y31L-N02
MMH-Y31T-N01
MMH-Y31T-N02
0.44" 0.64" 0.75"
FRL-4W, FRL-4Z 1/4"
3/8"
MMH-Y41-N02
MMH-Y41-N03
MMH-Y41L-N02
MMH-Y41L-N03
MMH-Y41T-N02
MMH-Y41T-N03
0.55" 0.71" 0.94"
FRL-5 3/8"
1/2"
MMH-Y61-N03
MMH-Y61-N04
MMH-Y61L-N03
MMH-Y61L-N04
MMH-Y61T-N03
MMH-Y61T-N04
0.61" 0.79" 1.18"

Spacers with Quick Exhaust Ports
Spacer with Quick Exhaust Port, for Clippard Maximatic FRLs
Threaded pipe adapters allow for a component to be quickly and easily removed from the airline for replacement or service. Adapters can be used to allow for different pipe diameters in the configuration.
Dimensions - Spacer with Quick Exhaust Port, for Clippard Maximatic FRLs
FRL Series Port
Size
Spacer Only L H W
FRL-2 1/8" NPT
1/4" NPT
3/8" NPT
MMH-PA-2P
MMH-PA-2Q
MMH-PA-2W
0.91" 0.87" 0.87"
FRL-3 1/4" NPT
3/8" NPT
1/2" NPT
MMH-PA-3Q
MMH-PA-3W
MMH-PA-3Z
1.02" 1.34" 1.14"
FRL-4W, FRL-4Z 3/8" NPT
1/2" NPT
MMH-PA-4W
MMH-PA-4Z
1.30" 1.65" 1.38"
FRL-5 3/4" NPT
1" NPT
MMH-PA-5A
MMH-PA-5B
1.58" 2.13" 2.17"

L and T Brackets

L brackets are included with the purchase of combination FRLS—to convert to T, use T bracket only. If no bracket is furnished, use T or L bracket with MMH-YXX spacer (ordered separately).


L Bracket for Mounting Clippard Maximatic FRLs Dimensions - L Bracket for Mounting Clippard Maximatic FRLs T Bracket for Mounting Clippard Maximatic FRLs T Bracket for Mounting Clippard Maximatic FRLs
FRL Series L Bracket T Bracket H1 H2 L LS HM TS RM HS1 HS2
FRL-1 MMH-B110L MMH-B110T 1.06" 2.13" 0.47" 0.18" 0.12" 0.20" 0.09" 0.79" 1.57"
FRL-2 MMH-B210L MMH-B210T 1.30" 2.60" 0.59" 0.22" 0.12" 0.20" 0.11" 0.94" 1.89"
FRL-3 MMH-B310L MMH-B310T 1.77" 3.54" 0.63" 0.28" 0.16" 0.28" 0.14" 1.38" 2.76"
FRL-4W, FRL-4Z MMH-B410L MMH-B410T 1.97" 3.94" 0.87" 0.35" 0.16" 0.28" 0.18" 1.57" 3.15"
FRL-4A MMH-B510L MMH-B510T 1.97" 3.94" 0.87" 0.35" 0.16" 0.28" 0.18" 1.57" 3.15"
FRL-5 MMH-B610L MMH-B610T 2.48" 4.96" 0.91" 0.47" 0.16" 0.41" 0.24" 1.97" 3.94"

Mounting Bracket for Clippard Maximatic Regulators and Stacked Filter-Regulators
Replacement Mounting Hardware for Regulators & Stacked Filter-Regulators

Brackets are included with the purchase of these components. No mounting screws are included with these brackets.



Dimensions - Mounting Bracket for Clippard Maximatic Regulators and Stacked Filter-Regulators
Part No. Bracket L LS H HS W WS RV LM ML WM RH HL
Regulator Filter-Regulator
MMR-1N MMFRS-1N MMH-B120 1.57" 1.10" 0.67" 0.43" 1.49" 0.98" 0.81" 0.48" 0.26" 0.18" 0.09" 0.08"
MMR-2P
MMR-2Q
MMFRS-2P
MMFRS-2Q
MMH-B220 2.17" 1.34" 1.05" 0.75" 1.97" 1.18" 1.32" 0.79" 0.60" 0.21" 0.11" 0.08"
MMR-3Q
MMR-3W
MMFRS-3Q
MMFRS-3W
MMH-B320 2.09" 1.57" 0.93" 0.55" 2.52" 1.55" 1.67" 0.98" 0.31" 0.26" 0.13" 0.08"
MMR-4W
MMR-4Z
MMR-4A
MMR-5B
MMFRS-4W
MMFRS-4Z
MMFRS-4A
MMFRS-5B
MMH-B420 2.76" 2.13" 1.15" 0.71" 3.12" 1.94" 2.07" 1.18" 0.41" 0.33" 0.17" 0.08"

Mounting Hardware
for Lubricators & Filters
Mounting Bracket for Clippard Maximatic Lubricators and Filters

Lubricators and Filters do not come with mounting brackets (must be purchased separately). These brackets come with two mounting screws.




Dimensions - Mounting Bracket for Clippard Maximatic Lubricators and Filters
Part No. Bracket Thd L LS H HS W WS RV LM ML WM RH HL
Filter Lubricator
MMF-2P MML-2P MMH-B240 M4 1.58" 1.06" 0.21" 1.18" 0.95" 0.74" 0.18" 1.03" 0.27" 0.33" 0.56" 0.08"
MMF-3 MML-3 MMH-B340 M4 2.09" 1.59" 0.26" 1.51" 1.24" 0.95" 0.17" 1.39" 0.35" 0.32" 0.77" 0.08"
MMF-4Z
MMF-4W
MML-4Z
MML-4W
MMH-B440 M5 2.76" 2.12" 0.34" 1.85" 1.49" 1.22" 0.22" 1.85" 0.45" 0.41" 0.77" 0.87"
MMF-4A MML-4A MMH-B540 M5 2.76" 2.13" 0.34" 1.89" 1.53" 1.24" 0.22" 1.79" 0.48" 0.41" 0.79" 0.09"
MMF-5 MML-5 MMH-B640 M6 3.54" 2.60" 0.43" 2.50" 2.03" 1.69" 0.26" 2.37" 0.59" 5.12" 0.43" 0.13"
