M-MAR-1P-5

More Views

M-MAR-1P-5

Pressure Regulator, G1/8 Inlet, M5 Outlet, Knurled Knob, 0.7-3.4 bar
Sorry, this combination of options is not available online.
Contact your nearest distributor for pricing.
2D Files2D Files
AdjustmentKnurled Knob (Std.)
Data SheetData Sheet
Force25 lb. nominal
Included Item(s)Nuts & Lockwashers
Input Pressure300 psig max (21 bar)
Materal, BodyBrass
Material, SealsNitrile (FKM Optional)
Material, Spring & StemStainless Steel
Max. Flow85 l/min @ 3.5 bar, 140 l/min @ 7 bar
MediumAir, Water* or Oil* (* non-relieving models)
Mount#15/323-32 thread.
Notes85 l/min @ 3.5 bar, 140 l/min @ 7 bar
Operating Pressure10 to 50 psig
Operating Temperature Range32 to 230°F (0 to 110°C)
Ports (Inlet / Outlet)Std. - R1/8 / M5
Relieving OptionRelieving (Standard)
Travel Arc7/32"
Weight0.1800
