Adjustment | Knurled Knob |
---|---|
Air Flow | 1250 l/min @ 100 psig (adjustable) |
Flow Control Mount (Inlet/Outlet) | 1/4" NPT/1/4" NPT F. Side |
Input PSI | 150 psig max. |
Material, Seals | Nitrile |
Medium | Air, Water or Oil |
Meter Out / Meter In | Meter Out |
Mount | Panel or In-Line |
Pressure to Open | Cracks at approximately 2 psig |
Product Line Brochure | Mechanical Valves |
Seals | Nitrile |
Temperature Range | 32 to 230°F |
Weight | 0.1300 |
Notes
Arrow in body shows direction of controlled flow
