M-TV-4DMPH

More Views

M-TV-4DMPH

4-Way 3-position toggle valves with outlet ports open to atmoshere in the center position. The valve can be spring center, 3-position detent or the "DM" provides a detent on one side and spring return on the other side. The TV-DM model can be used on the momentary side as a "jog" or manual control, and with the detented side for an automatic or "run" mode.
Estimated to ship within 5 business days
Quantities and lead times are changing daily due to supply chain challenges. We appreciate your patience and understanding.
Contact your local Clippard Distributor for volume discounts.

  • Detented & Momentary models available
  • #10-32 & 1/8" NPT styles

  • ActuationDetented/Momentary
    Force to Rotate Toggle8 oz. nominal
    Included Item(s)Nut & Lockwashers
    Input PSI10 bar max.
    Material, ToggleNickel-Plated Brass
    Max. Flow125 L/min @ 3.5 bar; 210 L/min @ 7 bar
    MediumAir
    MountM16 x 1 thread
    PortG1/8
    SealsNitrile Std., FKM & Krytox Optional
    Temperature Range0 to 110°C
    UnitMetric
    Weight0.1800
