Clippard Manifold Mounted Multi Check Valves

Clippard Manifold Mounted Multi Check Valves

The R-614 Multi Check Valve integrates four check valves in  one compact valve body. Take advantage of the many features of this versatile line including easy manifold mounted design, integrated circuitry, Octoport outlet design, maximized performance and more.

• Efficient design
• Eight air passages extend longitudinally through the body
  surrounding the valve cavity integrated circuit

The R-337 is a 3-way, spring-return, fully-ported, piloted valve with an independent check valve in the same body. It can be used Normally-Open, Normally-Closed, as a diverter or as a selector.

The R-338 is a 2-position, 3-way, double-piloted, fully-ported valve also with an independent check valve. It can be used Normally-Open, Normally-Closed, as a 2-position diverter or as a 2-way selector.

Media:  Air, Water or Oil
Flow: 9 scfm @ 100 psig
Pilot Pressure Minimum: R-337: 40 psig; R-338: 20 psig
Temperature: 32 to 180˚F
Working Pressure: Vacuum to 150 psig
Cracking Pressure: 0.5 psig

Versatility is the key when it comes to Clippard’s Minimatic® Modular Valves. Available in an unlimited variety of directional, flow, pressure and special control valves - each in a valve body designed to mount and link together with a simple piping system. The piping system eases assembly and plumbing, resulting in reduced labor costs, errors in installation, and the potential for plumbing leakage.

Part No.    Description
R-614        Multi Check Valve
R-337        3-Way, Spring Return, Fully-Ported, Piloted Valve
R-338        3-Way, 2-Position, Fully-Ported, Double Piloted Valve












Clippard 3-Way Modular Check Valves

Features
• Easy manifold-mounted design
• Integrated circuitry
• Octoport outlet design
• Indicator shows valve position
• Mutiple porting speeds piping
• Micro gap construction - snap action & no blow by
